F25A Pipe threading machine you can carry with just one hand! The mighty lightweight, built in safety features, too. By changing the Dies, you can threading to process 8A to 25A (1/4" to 1") Steel and Stainless steel pipes, BSPT, NPT, conduit, NPSM, and BSW. STANDARD ACCESSORIES : - Cutting Oil (50W-R 1L x 2 or 100SW-RN 0.5L x 4) - Hex key 3, 5 mm, Dies 1/2" - 3/4", 1" 1 set each - Die-head 1/2" - 1" Note: This product has four product numbers: F25A : BSPT, 220V / 205151 F25A : Conduit, 220V / 205153 F25AIII : 110V / 205160 F25AIII : 220V / 205161

F25A Series

[Model Number : 205151 / 205153 / 205160 / 205161]

The S40AIII is a small mainstream 110V pipe threading machine with a motor design with a brake to prevent entanglement . By changing the Dies, you can threading to process 8A to 40A (1/4" to 11/2") Steel and Stainless steel pipes, BSPT, NPT and BSW. - Small but powerful 500W Universal motor. - Easy to use, high productivity, excellent portability. - Both Manual Opening (S40a) and Uni-auto(S40AV) Die-heads available. - Pipe size can be adjusted simply by turning the lever nut. - Thread length can be adjusted just by changing the lever contact(Uni-auto Die-head). - Die-cast body allows high precision and stable threading. - A machine backed by a history of perfection. STANDARD ACCESSORIES : - Cutting Oil (50W-R) 2L - Hex key 3, 5 mm, Dies 1/2" - 3/4", 1" - 1 1/2" 1 set each - Die-head 1/2" - 1 1/2" Note: This product has two product numbers: S40A : Manual Die -head, 110V / 207402 S40AV : Uni-auto Die-head, 110V / 207540

S40A

[Model Number : 207402 / 207540]

A best seller among compact machines! By changing the Dies, you can threading to process 8A to 50A (1/4" to 2") Steel and Stainless steel pipes, BSPT, NPT and NPSM, BSW, UNC, Metric, BSPP, PF. Conduit, Grooving and Bevelling. - Small but powerful 1000W Universal motor. - Easy to use, high productivity, excellent portability - only 48 kg. - Pipe size can be adjusted simply by turning the lever nut. - Thread length can be adjusted by just changing the lever contact(except Manual Die-head). STANDARD ACCESSORIES : - Cutting Oil (50W-R) 2L - Hex key 3, 4, 5, 6 mm, Dies 1/2" - 3/4", 1" - 2" 1 set each - Die-head 1/2" - 2" Note: This product has nine product numbers: FP50A : BSPT, 220V, 50/60Hz / 218681 FP50A : BSPT, 110V, 50/60Hz, no legs / 218682 FP50AV : BSPT, 220V, 50/60Hz / 218243 FP50AV : NPT, 220V, 50/60Hz / 218249 FP50AV CE : BSPT, 230V, 50Hz, with Foot Switch / 218246 FP50AV : BSPT, 110V, 60Hz / 218247 FP50AV : BSPT, 220V, 50/60Hz, PLP / 218248 FP50AV CE/UKCA : BSPT, 110V, 50Hz, with Foot Switch / 218251 FP50AV : BSPT, 220V, 50/60Hz / 218245 FP50AV : BSPT, 220V, 50/60Hz, G-plug / 218250

FP50A Series

[Model Number : 218681 / 218682 / 218243 / 218249 / 218246 / 218247 / 218248 / 218251 / 218245 / 218250]

A best seller among compact machines! By changing the Dies, you can threading to process 8A to 50A (1/4" to 2") Steel and Stainless steel pipes, BSPT, NPT and NPSM, BSW, UNC, Metric, BSPP, PF. Conduit, Grooving and Bevelling. - Small but powerful 1000W Universal motor. - Easy to use, high productivity, excellent portability - only 48 kg. - Pipe size can be adjusted simply by turning the lever nut. - Thread length can be adjusted by just changing the lever contact(except Manual Die-head). - FR50A and FR50AV supports #300 Die heads and Dies. STANDARD ACCESSORIES : - Cutting Oil (50W-R) 2L - Hex key 3, 4, 5, 6 mm, Dies 1/2" - 3/4", 1" - 2" 1 set each - Die-head 1/2" - 2" Note: This product has four product numbers: FR50AV : BSPT, 220V, 50/60Hz, G-plug / 218224 FR50AV CE : BSPT, 230V, 50Hz / 218220 FR50AV CE/UKCA : BSPT, 110V, 50Hz / 218222 FR50A CE/UKCA : BSPT, 110V, 50Hz / 218652

FR50A Series

[Model Number : 218224 / 218220 / 218222 / 218652]

The NP80A pipe threading machine that gives you the best finish you've ever seen! By changing the Dies, you can threading 8A to 80A (1/4" to 3") Steel pipes, Stainless steel pipes, BSPT/NPT, BSPP, PF, Conduit, NPSM, Metric, UNC, BSW threads, Cut grooving and Bevelling. Based on totally new concept, the NP 80A is designed to be user-friendly, easily maintained and completely reliable. "A machine you can really trust. Easy to use, high productivity, excellent portability." A machine that gives you total control and satisfaction on the job. STANDARD ACCESSORIES : - Carbon Brushes 1 pair, Cutting Oil (50W-R) 4L - Hex key 3, 4, 5, 6 mm, Dies 1/2" - 3/4", 1" - 2", 2 1/2" - 3" 1 set each - Die-head 1/2" - 2" , 2 1/2" - 3" one each Note: This product has ten product numbers: NP80A : BSPT, 220V, 50Hz / 274670 NP80A CE : BSPT, 110V, 50Hz, with Foot Switch / 274672 NP80A : BSPT/110V, 60Hz, no legs / 274673 NP80AV : BSPT, 220V, 50/60Hz, G-plug / 274750 NP80AV CE : BSPT, 230V, 50Hz, with Foot Switch / 274751 NP80AV : BSPT, 220V, 50Hz / 274752 NP80A : NPT, 220V, 60Hz / 274753 NP80AV : BSPT, 220V, 50Hz / 274754 NP80AVIII CE : BSPT, 230V, 50Hz, with Foot Switch / 274701 NP80AVIII : BSPT, 220V, 50Hz / 274702

NP80A Series

[Model Number : 274670 / 274672 / 274673 / 274750 / 274751 / 274752 / 274753 / 275754 / 274701 / 274702]

Efficient 3 -speed transmission speeds up your work. The N100A is a long-selling low-noise large pipe threading machine. By changing the Dies, you can threading 65A to 100A (11/2" to 4") steel pipes, stainless steel pipes, BSPT/NPT threads, cut grooving and bevelling. - Less than 100 sec to make a perfect 4" pipe taper thread. Less than 20 sec for a 1" pipe taper thread. - Uni-auto Die-head for 1/2" - 2" pipe. Die are compatible with NP50A/NP80A Manual Die-heads and Uni-auto Die-heads. - Profiling Die-head for 21/2" - 4" pipe. REX original profiling system enables precise, straight tapers, with 20 mm dies performing at higher speed and requiring less power consumption. - Quick adjustable cutter. - Quiet, maintenance-free condenser motor. - Built-in tool box is convenient for on-site work. - Large-capacity scrap catcher allows for long-term work. - Threading size, thread length, and micro fine adjustment of thread diameter can all be adjusted easily. - Compact and lightweight for its class (123 kg), it can be set up by just two people. - NV-auto and Manual Die-heads can be mounted as options. - Model with voltage shift switch available. (35A576/35A602) STANDARD ACCESSORIES : - Cutting Oil (246-R or 50W-R) 4L - Hex key 3, 4, 5, 6, 8 mm, Dies 1/2" - 3/4", 1" - 2", 2 1/2" - 4" 1 set each - Die-head 1/2" - 2" , 2 1/2" - 4" one each Note: This product has nine product numbers: N100A : BSPT, 220V, 50Hz / 35A570 N100A : BSPT, 110/220V, 60Hz / 35A576 N100A : BSPT, 110V, 60Hz, no legs / 35A578 N100A : NPT, 220V, 50/60Hz / 35A580 N100A : BSPT, 220V, 60Hz, G-plug / 35A591 N100A : NPT, 120V, 60Hz / 35A599 N100A CE : BSPT, 230V, 50Hz, with Foot Switch / 35A513 N100A CE : BSPT, 110/220V, 50Hz, with Foot Switch / 35A602 N100A CE : NPT, 230V, 50Hz, with Foot Switch / 35A5H0

N100A

[Model Number : 35A570 / 35A576 / 35A578 / 35A580 / 350591 / 35A599 / 35A513 / 35A602 / 35A5H0]

Large-diameter pipe threading machine, 150A pipe threading machine features a low-noise condenser motor and two variable speeds for efficient threading. By changing the Dies, you can threading 65A to 150A (11/2" to 6") steel pipes, stainless steel pipes, BSPT/NPT threads, cut grooving and bevelling. - Uses condenser motor for quiet operation. - Efficient 2-speed transmission speeds up work. - Powerful hammer chuck holds large-diameter pipes securely. - Uses notch profiling Die-head, suitable for threading large-diameter pipes. - The notch profiling Die-head has low cutting resistance for optimum threading of large-diameter pipes. - Threading size, thread length and microfine adjustment of thread diameter can all be adjusted easily. STANDARD ACCESSORIES : - Cutting Oil (246-R or 50W-R) 4L - Hex key 3, 4, 5, 6, 8 mm, Dies 2 1/2" - 4"、5”　-6” 1 set each - Die-head 2 1/2" - 4", 5”　-6” one each - 4 legs Note: This product has four product numbers: 150A : BSPT, 220V, 50Hz / 366500 150A : BSPT, 220V, 60Hz, G-plug / 366602 150A : NPT, 220V, 60Hz, G-plug / 366616 150A : NPT, 120V, 60Hz / 366617

150A

[Model Number : 366500 / 366602 / 366616 / 366617]

The FP80A pipe threading machine that gives you the best finish you've ever seen! By changing the Dies, you can threading 8A to 80A (1/4" to 3") Steel pipes, Stainless steel pipes, BSPT/NPT, BSPP, PF, Conduit, NPSM, Metric, UNC, BSW threads, Cut grooving and Bevelling. Based on totally new concept, the FP80A is designed to be user-friendly, easily maintained and completely reliable. "A machine you can really trust. Easy to use, high productivity, excellent portability." A machine that gives you total control and satisfaction on the job. STANDARD ACCESSORIES : - Carbon Brushes 1 pair, Cutting Oil (50W-R) 4L - Hex key 3, 4, 5, 6 mm, Dies 1/2" - 3/4", 1" - 2", 2 1/2" - 3" 1 set each - Die-head 1/2" - 2" , 2 1/2" - 3" one each Note: This product has thirteen product numbers: FP80A : BSPT, 220V, 50Hz / 274690 FP80A : BSPT, 110V, 60Hz, SUS / 274691 FP80A CE/UKCA : BSPT, 110V, 50Hz, with Foot Switch / 274692 FP80A : BSPT, 110V, 60Hz, no legs / 274693 FP80AVIII CE : BSPT, 230V, 50Hz, with Foot Switch / 274711 FP80AVIII : BSPT, 220V, 50Hz / 274712 FP80AVIII : BSPT, 110V, 60Hz / 274713 FP80AV : BSPT, 220V, 50/60Hz, G-plug / 274760 FP80AV CE : BSPT, 230V, 50Hz, with Foot Switch / 274761 FP80AV : BSPT, 220V, 50Hz / 274762 FP80A : NPT, 220V, 60Hz / 274763 FP80AV : BSPT, 220V, 50Hz / 274764 FP80AV CE/UKCA : BSPT, 110V, 50Hz, with Foot Switch / 274765

FP80A Series

[Model Number : 274690 / 274691 / 274692 / 274693 / 274711 / 274712 / 274713 / 274760 / 274761 / 274762 / 274763 / 274764 / 274765]

Manual pipe threader.No power supply required! - Ratchet facilitates smooth operation. - Quick-reliase lever disengages Dies, so there's no need to rotate the unit back again to release it. - Made of cast iron, the main body is lightweight yet robust. Moving parts are heat-treated and reinforced to limit wear.

OSTER - Type RATCHET PIPE THREADER 112R / 114R

[Model Number : 1101D2 / 1101D4]

- This compact and lightweight model ensures optimum threading in elevated or confined places. - Ratchet supplied. - Proven versatility in applications for gas/water supply pipes and thin steel conduits (by replacing Dies).

BABY REED - Type RATCHET PIPE THREADER 2R

[Model Number : 1102R3 / 1102R4 / 1102RE / 1102RN]
